A wood steam generator is a type of heating system that uses wood as fuel to produce steam. The generated steam can then be used for various purposes such as heating buildings, or driving industrial processes.
Wood steam generator is favored for their use of wood, a renewable resource, as a fuel, and they can provide a relatively environmentally friendly thermal energy solution. LHG biomass fuel boilers are designed to efficiently convert heat energy from wood to steam for heating, hot water supply and industrial processes. They often offer considerable long-term benefits in terms of cost and energy efficiency.
|
Item Type |
LHG0.08-0.7-BMF |
LHG0.1-0.7-BMF |
|
|
Rated Evaporation (t/h) |
0.08 |
0.1 |
|
|
Rated Working Pressure(MPa) |
0.7 |
||
|
Saturated Steam Temperature(℃) |
171 |
||
|
Steam Outlet(DN) |
20 |
||
|
Sewage Outlet (DN) |
25 |
||
|
Safety Valve Port(DN) |
15×2 |
||
|
Water Intake(DN) |
15 |
||
|
Exhausted Gas Temperature(℃) |
135 |
130 |
|
|
Water Volume(L) |
27.6 |
29 |
|
|
Designed Fuel |
Light Oil or Natural |
||
|
Fuel Consumption(kg/h) |
14.4 |
18 |
|
|
Designed Efficiency |
≥83.2 |
≥82.8 |
|
|
Packing Size (mm) |
1650×720×1700 |
1700×760×1900 |
|
|
Weight(kg) |
640 |
780 |
|
LHG biomass fuel boilers are widely used in various industries and fields. Residential heating: Wood steam generators can be used for space heating and domestic hot water production in homes or small buildings. Commercial heating: They can also be used in larger commercial properties, such as hotels or offices, to provide central heating. Industrial processes: Industrial Settings can use wood steam generators for drying, cooking, or other heat-intensive processes.
LHG biomass fuel boiler uses biomass as fuel, energy saving and environmental protection, which is conducive to environmental protection. At the same time with a variety of intelligent control systems, intelligent design. Welding process for the whole process of certified welders to ensure product quality. At the same time, it is also equipped with an efficient dust removal and energy saving system to reduce pollutant emissions, while improving thermal efficiency and saving costs. It is also equipped with anti-dry burning protection, water shortage protection, water timeout protection and other safety alkenes to ensure safe use.
Choose our boiler, because of our superior quality products, but also our business for many years of good reputation, in the industry has a good response. We have rich production experience, as well as the relevant supporting certificates, such as EU CE serious,SGS quality certification, quality management system certification and so on choose us, will provide you with perfect service,
